Description
This LED flood light design comes with an adjustable flood mount that is easy to install and operate. The die cast aluminum housing is brown/bronze with a weatherproof IP65 rated. The light output distribution is an ideal Type III, designed with a shorting cap and 1-10V dimming option to provide full customization on whether this light is used on a timer or dusk to dawn photocell. Additionally, the lights are DLC certified with a 5 year warranty.
This product is listed under DesignLights Consortium® (DLC) which does not only provide eligibility for rebates from most utility providers, but also promotes high-quality and energy-efficient lighting products through vigorous testing protocols.
Specifications
SKU: 106-100342 (5700K)
Certification: UL, DLC 5.1
Watts: 150W
Lumens: 145 lm/w
Color: 5700K
Lumens Output: 21750 Lumens
CRI: >80
Distribution: Type III
Input Voltage: 120-277 VAC 50/60Hz
Lifespan: 50,000 hours
Dimming: 1-10V
Shorting cap: Included
Weight: 9.23 lbs
Warranty: 5 years
Power Factor (PF): ≥0.9
Driver: HBE
IP Grate: IP65 Rated
LED: Lumileds
Housing: Die-cast aluminum
Replaces: up to 500W MH/HPS
Dimension: 13.82" x 14.53" x 3.27"
LED Type: SMD2835
Mounting accessory: Flood Mount
Motion Sensor: No (Can order by special order)
EPA: 1 ft²
BUG: B4-U3-G2
Product Spec Sheet
Click here for product specification sheet
Installation Guide
Click here for installation guide
